DBI233IB.W/1
DBI233IB.W/1

DBI233IB.W/1

Drying system: Turbo Combi Drying™
Product line: Classic
Installation: Built-in
Size: XL, 820 mm
Number of baskets: 2
Number of place settings (label): 13 place settings
Upper basket type: Premium - Basket wiring in steel, fixed pin rows and foldable wine shelves.
Lower basket type: Premium - Basket wiring in steel, fixed pin rows and removable cutlery basket.
Handle with stainless steel logotype: Handle with Stainless steel logotype
Cutlery basket: Removable cutlery basket for easy loading and unloading
8 Steel™ - Vital parts of the dishwasher made in stainless steel.SCS+

Share

Twitter
Linkedin

Highlights

SCS - Super Cleaning System™
SCS - Super Cleaning System™
8 Steel™
8 Steel™
Turbo Combi Drying™
Turbo Combi Drying™
Aqua Safe™ system
Aqua Safe™ system
Flexiracks™
Flexiracks™
XL Dishwashers
XL Dishwashers
Hygiene
Hygiene
Time program
Time program
Eco
Eco
Brushless motor
Brushless motor
Speed mode
Speed mode
Night mode
Night mode
Quick wash
Quick wash
Rinse & hold
Rinse & hold
Aqua Level™Sensor
Aqua Level™Sensor
Aqua Detect™ Sensor
Aqua Detect™ Sensor
Power Zone Cutlery™
Power Zone Cutlery™
Kid Safe™
Kid Safe™
Anti siphon
Anti siphon
Wide Spray™
Wide Spray™
7 Spray™
7 Spray™
2 Level baskets
2 Level baskets
Telescopic rails
Telescopic rails
2 Spray arms
2 Spray arms
13 - Loading capacity
13 - Loading capacity
Pop Out Door
Pop Out Door
Knife holders
Knife holders
Multi position glass rack
Multi position glass rack
20 years
20 years
SCS - Super Cleaning System™
SCS - Super Cleaning System™

SCS - Super Cleaning System™

Rinse the dishes. Clean the interior, including the filter. Choose the best program. How many steps is that? One – and we call it the Super Cleaning System – or our best invention.
8 Steel™
8 Steel™
8 Steel™

8 Steel™

No other material lasts as long as steel. And no other dishwashers have as many details made from steel instead of plastic as ASKO dishwashers. In fact, eight of the most important components in our dishwashers are made of high-quality steel rather than plastic: the container, loading racks, spray pipe, spray arms, strainers, outer base, feet, and inner door. By using more steel and less plastic, we make our machines last longer.
Turbo Combi Drying™
Turbo Combi Drying™
Turbo Combi Drying™

Turbo Combi Drying™

Turbo Combi Drying™ benefits from both the innovative Turbo Drying™ system and natural drying with dry indoor air. Our Turbo Drying™ system begins the drying process and is followed with the door automatically opens to finish the drying with indoor air.
Aqua Safe™ system
Aqua Safe™ system
Aqua Safe™ system

Aqua Safe™ system

Aqua Safe™, is an advanced water safety system encompassing both a sturdy construction like PEX hose and seam-welded stainless container as well as smart systems as anti-block drain pump, Aqua Detect sensor and stand-by water protection. Few sealing points outside the container Seem-welded container in stainless steel Waterproof external base Exterior Float Aqua Detect™ Sensor Stand by water protection PEX inlet hose Maximum time for water intake Light and sound alarm Anti-block drain pump Safety Inlet Valve
Aqua Safe™ system
Flexiracks™
Flexiracks™

Flexiracks™

ASKO Flexiracks™ from sturdy, nylon coated steel and are easily adjustable in different heights depending on which type of load you have.
XL Dishwashers
XL Dishwashers
XL Dishwashers

XL Dishwashers

Our XL dishwashers have an loading height of 54 cm. Combined with the smart four level rack system the load is 40% more, with countless possibilities to make it all fit in.
Hygiene
Hygiene
Hygiene

Hygiene

The Hygiene program washes and rinses at 70°C and is perfect for baby bottles, cutting boards and jars for your home made marmalade.
Hygiene
Hygiene
Time program
Time program
Time program

Time program

When you need clean plates in a hurry, just tell the machine how dirty the dishes are and how much time you have. The program then adjusts washing and rinsing to match your needs.
Time program
Time program
Eco
Eco
Eco

Eco

Use when you want to save water and energy. For normally soiled load, such as plates, serving dishes, cups, glasses and so on.
Eco
Brushless motor
Brushless motor
Brushless motor

Brushless motor

A brushless motor is not only quieter and more reliable. It also consumes less energy. You want your dishwasher to work forever. So do we.
Speed mode
Speed mode
Speed mode

Speed mode

When you need to get things cleaned in a hurry, the Speed mode is useful. It saves up to 50% of the normal time, by using more water and increased heating.
Night mode
Night mode
Night mode

Night mode

Night mode reduces the noise with 2 dB thanks to lower pressure in the spray arm. Perfect at night or in a house with an open plan living area.
Night mode
Night mode
Quick wash
Quick wash
Quick wash

Quick wash

The Quick Wash programme washes lightly soiled glasses, decanters, coffee cups etc. efficiently and leaves your kitchen ware as spotless as you want them to be.
Rinse & hold
Rinse & hold

Rinse & hold

The Rinse and hold program allows for you to avoid dried leftovers while you wait for the dishwasher to get fully loaded. Saves time and energy over time.
Aqua Level™Sensor
Aqua Level™Sensor
Aqua Level™Sensor

Aqua Level™Sensor

The Aqua Level™ Sensor ensures the exact amount of water. For example, if a plastic bowl turns over and is filled with water, the sensor automatically adds extra water to the process for a premium cleaning result.
Aqua Detect™ Sensor
Aqua Detect™ Sensor
Aqua Detect™ Sensor

Aqua Detect™ Sensor

The Aqua Detect™ Sensor monitors the inlet valves and the water level while the machine operates. For safety reasons, the drain pump’s capacity is five times the inlet valve’s.
Power Zone Cutlery™
Power Zone Cutlery™
Power Zone Cutlery™

Power Zone Cutlery™

Power Zone Cutlery™ is a special nozzle spray zone for the cutlery basket that will make your cutlery dazzling clean. And, there is a similar nozzle for the knife basket.
Kid Safe™
Kid Safe™
Kid Safe™

Kid Safe™

To stop small fingers from starting the dishwasher the Kid Safe™ makes the control panel easy to lock. This also prevents altering any settings by mistake.
Anti siphon
Anti siphon
Anti siphon

Anti siphon

For our fully integrated dishwashers, the Anti-siphon solution safely keeps the water inside the machine. This is especially important if the dishwasher is placed above floor level.
Wide Spray™
Wide Spray™
Wide Spray™

Wide Spray™

WideSpray™ which creates a high-pressure jet spray in combination with a wide spraying nozzle. The pots and pans becomes clean and you get time to widen your scope.
7 Spray™
7 Spray™
7 Spray™

7 Spray™

ASKO’s spray system consists of up to 7 effective spray zones to ensure a totally clean load. In the lower rack there are three power zones to take care of the dirtiest parts.
2 Level baskets
2 Level baskets
2 Level baskets

2 Level baskets

ASKO’s four level rack system allows you to optimize the load. Remove, adjust, fold and move the racks, pin rows and cutlery basket to meet your every need.
Telescopic rails
Telescopic rails
Telescopic rails

Telescopic rails

ASKO uses telescopic guide rails with ball bearings to make the racks glide smoothly and quietly. For easy loading and unloading, you can also take out the whole rack.
Telescopic rails
2 Spray arms
2 Spray arms
2 Spray arms

2 Spray arms

The 2 spray-arm technique reaches every corner and with up to 10 highly effective spray zones, no dirt can escape. Not even your lasagne baking dish.
13 - Loading capacity
13 - Loading capacity
13 - Loading capacity

13 - Loading capacity

Inspired by everyday life. Our goal is that our products should make your everyday life simpler. That is why we have worked so hard through the years to develop the market’s largest and most flexible basket systems. This time, we have been especially careful to first find out what people really put in their dishwashers. We then translated our newly acquired knowledge to a range of unique, innovative and practical basket solutions.
Pop Out Door
Pop Out Door

Pop Out Door

When a program is completed, the Door Pop-Out function opens the dishwasher door automatically to remove the steam inside.
Pop Out Door
Knife holders
Knife holders
Knife holders

Knife holders

Knives are sensitive things, so too are fingers. That is why we have done everything possible to protect both as best we can. Our knife holder is extra deep so that the blades remain steady throughout the wash cycle. There are knife holders on three levels: in the middle basket, in the upper basket and in the top basket. We guarantee a clean cut.
Multi position glass rack
Multi position glass rack
Multi position glass rack

Multi position glass rack

The Multi position glass rack is a very practical rack that can be mounted in three different positions – all depending on your needs.
20 years
20 years
20 years

20 years

Today, sustainability and responsibility go hand in hand. So when we design our products, it is our responsibility to not only make products that last, but which also make things better – for our customers and for the planet. Designed to make a difference. And built to be enjoyed for the next 20 years.

Construction & Performance

Extra durable stainless steel container.
Aqua Detect™ - Instant recognition of any leakage in the motor compartment.
Stand-by water protecion - Leakage detection when machine is off.
Anti Block™ - Self cleaning drain pump.
8 Steel™ - Vital parts of the dishwasher made in stainless steel.
Hidden heater
No need to rinse the dishes thanks to Super Cleaning System™
Automatic water-softener for better washing performance
Number of spray arms: 2
Number of spray zones: 7
Wide Spray™ - Extra dishwashing power for pots and pans
Turbo Combi Drying™
TotalDry – automatic door opening
Cutlery Spray™ - Extra dishwashing power for the cutlery basket

Use & flexibility

Number of place settings (label): 13 place settings
Number of baskets: 2
Upper basket type: Premium - Basket wiring in steel, fixed pin rows and foldable wine shelves.
Guide rails with ball bearings
Lower basket type: Premium - Basket wiring in steel, fixed pin rows and removable cutlery basket.
Small distance between the basket threads - makes loading easy and prevents small items to fall through.
Removable cutlery basket for easy loading and unloading
Required inlet water pressure: 0,03-1 MPa

Interaction & Control

Type of display: LCD display
Ability to create own programmes: Memory programme
Number of programs: 7
Number of options: 5
Time remaining indicator: Front display
Wash end indication: Displayed with sound and light
Available languages in control unit: DA, DE, EN, ES, ET, FI, FR, HR, IT, JA, LT, LV, NL, NO, PL, PT, RU, SL, SV, ZH, ZH-CN

Programs

7 programmes: Quick; Intensive; Eco; Hygiene; Time program; Rinse & hold; Universal
Delayed start: Possible to delay up to 24 hours
Time set
Speed mode - The program time is shortened. More energy is used.
Night mode - Lower noise level. The program time is extended.
Super Rinse™ - Two extra rinses.

Design & integration

From front adjustable rear foot
Integrated anti-siphon - Prevents spontaneous in- and outlet of water and simplifies elevated installation
Min. niche width: 600 mm
Min. niche height: 820 mm
Depth (incl. wall spacing): 560 mm
Height setting: 50 mm
Possible adjustment of kick plate: 30 - 94/0 mm

Safety & Maintenance

Aqua Safe™ system - Multiple safety systems preventing water damages.
Kid Safe™ - Lockable controls
Indication of low level of rinse-aid: Notification in display
Salt refill indicator: Salt refill indicator

Technical data

Water connection: Size 3/4" - Can be connected to hot or cold water
Max. temperature of incoming water: 70 °C
Noise level: 44 dB(A)re 1 pW
Reference program: 1
Duration of label wash cycle: 205 min
Estimated annual energy consumption: 206 kWh
Energy consumption - normal program: 0,72 kWh
Estimated annual water consumption: 2492 l
Water consumption - label program: 8,9 l
Energy consumption in off mode: 0,49 W
Energy consumption in standby mode: 0,49 W
Energy class: A+++
Plug type: Euro
Connected load: 1900 W
Voltage (V): 220-240 V
Number of phases: 1
Fuse: 10 amp
Frequency: 50 Hz
Required inlet water pressure: 0,03-1 MPa
Net weight: 40,5 kg

Dimensions

Width: 596 mm
Height: 819 mm
Depth: 559 mm
Maximum product height: 869 mm
Length electrical cord: 1825 mm
Depth with door open: 1198 mm
Length inlet hose: 163 cm
Length outlet hose: 200 cm

Logistic information

Packaging width: 640 mm
Packaging height: 890 mm
Packaging depth: 680 mm
Gross weight: 43,8 kg
Product code: 736818
EAN code: 3838782484179
Market: Domestic
